PGM401 TFB
PGM401 Tri-fade Burst Red copyright sprite

The PGM401 is a PGM series solid body electric guitar model introduced by Ibanez for 2009. It is a signature model of American guitarist Paul Gilbert. It replaced the PGM301.

The PGM401 has a more 'classic' approach than the PGM301 with a sunburst finish, an RG-style ash body, DiMarzio Air Classic pickups which give a more "vintage" tone, a bone nut and Gotoh tuning machines. It also abandons the more modern All Access Neck Joint of the previous Gilbert models in favor of the traditional Tilt Joint, which Gilbert believes provides a "fatter" sound.

The signature painted F-holes of the PGM models are 3% smaller on the PGM401 to retain a balanced look with the pickup rings.

The PGM401 was discontinued after 2011.

Specifications[]

Specifications for PGM401
Model name: PGM401
Year(s) offered: 2009–2011
Sold in: Worldwide
Made in: Japan
Finish(es): Tri-fade Burst (TFB)
Body
Body type:
Solid body
Body material:
Ash
Neck joint:
Tilt Joint
Bridge:
Gotoh GTC101 fixed (10.5mm string spacing)
Knob style:
Plastic top hat (black)
Hardware color:
Cosmo black
Neck
Neck type:
PGM Prestige
Neck material:
5-piece maple/ walnut
Scale length:
648mm/ 25½"
Fingerboard material:
Rosewood
Fingerboard inlays:
Pearl dot
Frets:
24 / medium (SBB214-175)
Nut:
Bone (43mm)
Machine heads:
Gotoh SG381 (non-locking)
Electronics/ Strings
Pickup configuration:
HH
Bridge pickup:
DiMarzio Air Classic neck (H)
Neck pickup:
DiMarzio Air Classic bridge (H)
Switch:
VLX91
Controls:
Master volume / 5-way lever pickup selector
Output jack:
¼" stereo barrel (side mounted)
Factory tuning:
1E,2B,3G,4D,5A,6E (E Std.)

Images[]

Additional \details
PGM401 front
Front of body
PGM401 rear
Rear of body
PGM401 case
PGM401 w/ case
PGM401 HH 5WAYLEV 1V
Control layout & pickup switching
